Neoprene Rubber Gasket Technical Specifications & Engineering Properties
Advanced Technical Performance of RUBBER-KU Neoprene Rubber Gasket
RUBBER-KU Neoprene Rubber Gaskets are manufactured using premium-quality Chloroprene Rubber (CR) compounds engineered to provide outstanding sealing performance, excellent environmental resistance, and superior mechanical durability. These gaskets are specifically designed for industrial flange connections, pipelines, pumps, valves, tanks, HVAC systems, marine equipment, water treatment facilities, and general engineering applications where dependable sealing is essential.
Neoprene Rubber is one of the most technically balanced elastomers available in the gasket industry, offering an ideal combination of weather resistance, oil resistance, ozone resistance, mechanical strength, flexibility, and long-term service reliability.
Material Technical Information
Material Type
Neoprene Rubber (CR – Chloroprene Rubber)
Polymer Family
Synthetic Chloroprene Elastomer
Material Classification
General-Purpose Industrial Sealing Rubber
Compound Type
Commercial Grade, Industrial Grade, Premium Grade, Flame Retardant Grade, FDA Grade
Manufacturing Process
Compression Moulded, Die-Cut, CNC Cut, Water Jet Cut, Custom Fabricated
Physical Properties
Hardness Range
Standard Hardness:
50 Shore A ±5
60 Shore A ±5
65 Shore A ±5
70 Shore A ±5
80 Shore A ±5
Custom hardness available upon request.
Technical Benefits
- Improved flange conformity
- Better sealing performance
- Enhanced compression recovery
- Suitable for low and high bolt loads
Tensile Strength
Typical Range:
7 MPa – 20 MPa
Higher grades available for demanding industrial applications.
Technical Benefits
- Resists stretching under load
- Improved durability
- Enhanced gasket integrity
- Reduced risk of mechanical failure
Elongation at Break
Typical Range:
250% – 500%
Technical Benefits
- Excellent flexibility
- Improved installation performance
- Better resistance to mechanical stress
- Increased durability under movement
Tear Resistance
Neoprene exhibits excellent tear strength characteristics.
Technical Benefits
- Reduced installation damage
- Improved durability
- Better resistance to flange edge stress
- Increased service life
Compression Set Resistance
Typical:
15% – 35%
Depending on compound grade and operating temperature.
Technical Benefits
- Maintains sealing force
- Reduces leakage risk
- Long-term gasket recovery
- Extended operational lifespan
Temperature Resistance
Continuous Operating Temperature
-20°C to +100°C
Intermittent Temperature Range
Up to +120°C
Special formulations may accommodate higher operating temperatures.
Technical Benefits
- Stable sealing performance
- Thermal cycling resistance
- Reduced thermal degradation
- Long service life
Weather Resistance Properties
One of the most important technical advantages of Neoprene is its outstanding weatherability.
Neoprene resists:
- UV radiation
- Ozone attack
- Atmospheric oxidation
- Rain exposure
- Tropical climates
- Humidity
- Outdoor aging
Technical Benefits
- Outdoor durability
- Extended gasket lifespan
- Reduced maintenance costs
- Reliable environmental performance
UV Resistance Performance
Neoprene demonstrates exceptional resistance to ultraviolet degradation.
Unlike natural rubber materials, CR compounds maintain:
- Surface integrity
- Elasticity
- Tensile strength
- Compression properties
Even after prolonged outdoor exposure.
Applications
- Outdoor pipelines
- Solar installations
- Water treatment plants
- HVAC rooftop systems
- Marine environments
Ozone Resistance Performance
Atmospheric ozone is a major cause of rubber cracking.
Neoprene possesses excellent ozone resistance properties.
Technical Benefits
- Crack prevention
- Improved durability
- Long-term elasticity
- Extended operational reliability
Oil Resistance Characteristics
Neoprene offers good resistance to petroleum-based products.
Compatible with:
- Lubricating oils
- Hydraulic fluids
- Compressor oils
- Gear oils
- Industrial greases
- Petroleum lubricants
Technical Benefits
- Reduced swelling
- Improved dimensional stability
- Longer gasket life
- Better equipment protection
Chemical Resistance Properties
Neoprene provides good resistance to a broad range of industrial chemicals.
Suitable for exposure to:
- Mild acids
- Mild alkalis
- Detergents
- Cleaning agents
- Industrial process water
- Refrigerants
- Ammonia solutions
Technical Benefits
- Improved chemical stability
- Enhanced sealing reliability
- Reduced material degradation
- Lower maintenance frequency
Water Resistance Performance
Neoprene exhibits excellent resistance to water absorption.
Suitable for:
- Fresh water
- Industrial water
- Rainwater
- Moisture
- Condensation
- Humid environments
Technical Benefits
- Leak prevention
- Reduced swelling
- Stable sealing performance
- Enhanced service life
Abrasion Resistance
Neoprene demonstrates excellent wear resistance characteristics.
Suitable for:
- Vibrating equipment
- Moving assemblies
- Industrial machinery
- Mechanical installations
Technical Benefits
- Reduced wear
- Improved durability
- Longer maintenance intervals
- Better operational reliability
Vibration Isolation Characteristics
Neoprene naturally absorbs vibration and shock loads.
Widely used in:
- Pumps
- Compressors
- Motors
- Blowers
- HVAC equipment
- Rotating machinery
Technical Benefits
- Noise reduction
- Equipment protection
- Reduced stress on connections
- Improved system stability
Electrical Properties
Flame Retardant Neoprene grades offer enhanced electrical insulation characteristics.
Suitable for:
- Electrical cabinets
- Switchgear
- Control panels
- Generator systems
- Power distribution equipment
Technical Benefits
- Improved safety
- Enhanced insulation
- Fire protection
- Equipment reliability
Flame Retardant Performance
Special FR Neoprene compounds provide self-extinguishing characteristics.
Benefits
- Improved fire safety
- Reduced flame propagation
- Compliance with industrial requirements
- Enhanced operational protection
Available Thickness Range
RUBBER-KU manufactures Neoprene Rubber Gaskets in various thicknesses including:
1.0mm
1.5mm
2.0mm
3.0mm
4.0mm
5.0mm
6.0mm
8.0mm
10.0mm
12.0mm
15.0mm
20.0mm
25.0mm
Custom thicknesses available upon request.
Available Size Range
Standard Sizes:
DN15
DN20
DN25
DN32
DN40
DN50
DN65
DN80
DN100
DN125
DN150
DN200
DN250
DN300
DN400
DN450
DN500
DN600
Custom gasket dimensions and non-standard flange configurations can be manufactured according to engineering drawings.
International Standards Compatibility
RUBBER-KU Neoprene Rubber Gaskets can be manufactured according to:
- ANSI 150
- ANSI 300
- BS Table D
- BS Table E
- BS Table F
- JIS 5K
- JIS 10K
- JIS 16K
- DIN PN6
- DIN PN10
- DIN PN16
- DIN PN25
- DIN PN40
- Custom OEM Standards
Engineering Advantages of RUBBER-KU Neoprene Rubber Gasket
Excellent Environmental Resistance
Provides superior protection against outdoor exposure.
Outstanding Mechanical Strength
Maintains sealing integrity under demanding conditions.
Superior Compression Recovery
Ensures long-term leak-free performance.
Excellent Oil Resistance
Suitable for machinery and industrial equipment.
Reliable Chemical Compatibility
Performs well in diverse industrial environments.
Vibration Dampening Capability
Protects equipment and extends service life.
Long-Term Operational Reliability
Minimizes downtime and maintenance costs.
Cost-Effective Engineering Solution
Offers an excellent balance between performance and affordability.
Why Engineers Choose RUBBER-KU Neoprene Rubber Gaskets
✔ Premium Chloroprene Rubber (CR) Compound
✔ Precision Manufacturing Accuracy
✔ Consistent Material Quality
✔ Excellent Weather Resistance
✔ Outstanding UV & Ozone Resistance
✔ Good Oil & Chemical Resistance
✔ Wide Temperature Capability
✔ Superior Compression Set Resistance
✔ Excellent Mechanical Strength
✔ Long Service Life
✔ Multiple Industrial Grades Available
✔ Custom Manufacturing Capability
✔ Factory Direct Supply
✔ Technical Engineering Support
✔ Trusted by Industrial Professionals Across Malaysia
RUBBER-KU Neoprene Rubber Gaskets are engineered to meet the demanding requirements of industrial sealing systems, delivering exceptional technical performance, durability, and reliability for water treatment, marine, HVAC, automotive, power generation, manufacturing, construction, and general engineering applications throughout Malaysia and Southeast Asia.
